Overview
Description
360 KIWI KRAFT DINGHY is a compact, alloy pontoon dinghy designed as a stable, safe and durable small boat for up to three people. With a 3.6 m overall length, wide 1.68 m beam and 17° deadrise, it provides good stability at rest and predictable handling with outboard power up to 30 hp.
The hull, pontoons and floor are constructed from robust aluminium plate (3 mm hull and pontoons, 4 mm floor), with generous freeboard (450 mm floor to gunwale) and sealed pontoons for added buoyancy. Simple, open internal layout with removable seating makes it suited to inshore fishing, tender duties and general small-boat use.
Standard equipment includes key handling and safety features such as scuppers, grab rails and cleats, while an extensive range of optional extras allows customisation for different uses – from additional seating and anchoring gear to a bolt-on side console, fuel and battery tie-downs, and boarding/swim hardware.
Specifications
- LOA (overall length): 3600 mm
- Beam: 1680 mm
- Internal beam: 1190 mm
- Deadrise: 17°
- Hull thickness: 3 mm aluminium
- Pontoon thickness: 3 mm aluminium
- Floor thickness: 4 mm aluminium
- Floor to gunwale height: 450 mm
- Maximum engine power: 30 hp (outboard)
- Maximum capacity: 3 persons
Standard Features
- Front fairlead
- Scuppers
- Single removable seat
- Front grab rails
- Internal rail
- Rear cleats
Optional Extras
- Additional single seat
- Bench seat
- Anchor bulkhead
- Full length bow and grab rail (external)
- Bollard
- Extra cleats
- Side console (bolt or weld on)
- Fuel tank tie-down
- Battery tie-down
- Swim platform
- Boarding ladder
Notes
Note: Specifications can change without prior notice.
