Asking PriceDealer
Price on Application
MakeKiwi Kraft
Model470 CUDDY
Length4.7m
Overview
About this vessel
Kiwi Kraft 470 Cuddy is a compact, alloy pontoon boat built to New Zealand CPC standard and MSA specifications, designed to offer a secure, soft-riding platform for inshore and sheltered offshore fishing. Its multiple sealed pontoon buoyancy chambers and Hush Tec technology contribute to superior performance, safety and noise reduction on the water.
The hull construction features 3 mm alloy for the hull, pontoons and topsides with a 4 mm alloy floor, delivering a robust yet relatively light 299 kg hull weight. With an overall length of 4.7 m, a beam of 1.935 m and an internal beam of 1.35 m, the 470 Cuddy is trailerable, easy to handle and well suited to smaller tow vehicles while still providing a stable, high-freeboard fishing platform.
The layout centres around a compact cuddy cabin forward with a foredeck hatch, high gunnels (700 mm floor to gunnel), rear boarding platform and functional cockpit space. Standard equipment includes rotary non-feedback steering, an outboard pod, small fillet board, transom rail with ski hook, rod holders and ample storage solutions such as side pockets, a battery shelf and battery box with ISO switch.
The 470 Cuddy is configured for tote tank fuel and is rated to a maximum of 60 hp outboard, carrying up to four persons on board (4 POB). It is set up for fishing and general family boating, with standard bilge pump, transducer mount and water pick-up and valve assembly, and can be further customised via a wide range of optional extras including live bait tank, deck wash, boarding ladder, rocket launcher and various anchoring systems.
Key construction and configuration details include:
- LOA 4700 mm with 1935 mm beam and 18° deadrise
- 3 mm alloy hull, pontoons and topsides with 4 mm alloy floor
- Built to NZ CPC and MSA standards with multiple sealed pontoon buoyancy chambers
- Hush Tec technology for a softer, quieter ride
- Hull weight of 299 kg, designed for a maximum of 60 hp and 4 persons
Standard features focus on safety, functionality and ease of use:
- Built to NZ CPC standard & MSA specifications
- Hush Tec technology for superior performance
- Multiple sealed pontoon buoyancy chambers
- Rear boarding platform
- Heavy-duty fender rubber
- Foredeck hatch
- Rotary steering (NFB – non feedback)
- Outboard pod
- Small fillet board
- Bilge pump 1100 GPH
- 1500 seats
- Rear sliding seat
- Soft rider pedestals and sliders
- Transom rail and ski hook
- Rod holders x 4
- Battery box & ISO switch
- Side pocket storage
- Battery shelf
- Transducer mount
- Zinc anode
- Water pick up and valve assembly
Optional extras allow the 470 Cuddy to be tailored for more intensive fishing or general boating:
- Live bait tank with manual pick up and pump
- Deck wash pump and hose storage tube
- Boarding ladder (2 or 3 rung)
- Rocket launcher
- Capstan winch
- Anchor windlass
- Anchor drum winch
- Pot hauler
- Hydraulic steering
- Hydraulic steering recess kit
- Seat upholstery kits
- CPC compliance kit
Note: Specifications can change without prior notice.
Specifications
The details
Vessel
MakeKiwi Kraft
Model470 CUDDY
Dimensions
Length overall4.7m
